Mobile Economic Fume Extractor

Model: TOMJ-07

The TOMJ-07 is a compact, mobile fume extraction unit designed to effectively remove smoke, dust, and fumes generated from welding, grinding, and other industrial applications. Engineered for flexibility and efficiency, this unit is ideal for individual workstations and portable use.

Equipped with a high-performance filtration system and flexible suction arm, the TOMJ-07 ensures a clean and safe working environment by capturing harmful particles directly at the source. It also supports rare metal and valuable material recovery applications.

• Efficient Filtration System: Three-stage purification includes a spark arrestor, diversion panel, and a high-efficiency main filter cartridge, with a filtration rate of up to 99.9%, meeting indoor air discharge standards.

• 360° Flexible Suction Arm: Rotates freely and holds position without external force. Available in 2m, 3m, or 4m lengths with a 160mm diameter, made from flame-retardant, wear-resistant composite material.

• Smart Dust Cleaning Modes: Supports semi-automatic and manual back-blowing cleaning methods for easy maintenance and longer filter life.

• User-Friendly Design: Mounted on four polyurethane wheels (2 directional, 2 universal with brakes) for easy relocation between welding stations.

• Advanced Safety Features: Built-in protection includes power phase sequence indicator, short circuit protection, optional over-temperature automatic shutdown, and overpressure back-blow protection.

• Imported Filter Material: Main filter cartridge made from premium imported wood pulp fiber, capable of filtering particles as small as 0.5μm.
